KEYSION CS43198 USB-C to 3.5mm DAC Headphone Amp, 384kHz DSD256, Black

KEYSION CS43198 USB Little Tail DAC Audio HiFi Decoder 384KHz DSD256 Type-C to 3.5mm HD Headphone Amplifier for iOS Android PC

Input: TYPE-C

Output: 3.5mm Earphone Port

DAC Chip1: Cirrus Logic CS43198

Bit depth: 16/24/32bit

PCM Specification: 44.1/48/88.2/96/176.4/192/352.8/384KHz

DSD Specification: DSD64/128/256/

USB Output DSD Audio Support Mode: DOP (DSD64/1286)

Native:DSD64/128/256

Signal to noise ratio/SNR：130dB

Dynamic range/DNR: 130dB

Distortion/THD+N: -115dB

Frequency response/FR：20Hz-40kHz+/-0.1dB

Thrust impedance: 16-600Ω Adaptive.

DAC Chip 2: Primachip CB5100

ADC:48KHz/24bit

Features:

1:layback supports flexible adjustment configuration of 10-segment EQ/5 filter modes and WALK PLAY APP EQ linkage

2:The maximum compatible recording sound quality is 48KHz/24bit, greatly improving the sound quality during recording.

3:Equipped with recording/calling/Android standard remote control function.

4:Equipped with status indicator light effect (standby - blue, PCM green, exclusive DSD red)

Core material: Single Crystal Copper

Shell material: Aluminum Alloy CNC+Matte Acrylic Translucent cover plate

Product weight: 19g

Support : 99% USB TYPE-C Ports for smart devices, smartphones / tablets / iOS / Mac / Win10/11
